In today’s fast-paced digital age, the BIA HDR 4K LED Video Wall stands out as a technological marvel, bringing the wow factor to visual displays. Let’s take a journey into the world of BIA SMD screens, exploring their components, reliability, latest design, installation ease, HDR 4K visuals, popularity, and the myriad uses and benefits they offer.
BIA SMD (Surface Mount Device) screens are cutting-edge display solutions that use tiny LED packages to create vibrant and seamless visuals. These screens are composed of small, individual LEDs mounted directly onto the display surface, resulting in a sleek and immersive viewing experience. Imagine a jigsaw puzzle of tiny, powerful lights coming together to form a larger-than-life picture.
The BIA HDR 4K LED Video Wall boasts a robust set of components that contribute to its reliability and performance. Each LED package is carefully crafted to ensure longevity and consistent brightness. The screen is built with precision, incorporating advanced technologies that make it resistant to wear and tear, providing users with a reliable and durable display solution.
The latest design of BIA HDR 4K LED Video Wall is a sight to behold. With a sleek profile and minimal bezels, it offers an immersive viewing experience that captivates the audience. The design not only focuses on aesthetics but also prioritizes functionality, making it a perfect fit for various settings, from corporate boardrooms to entertainment venues.
One of the standout features of the BIA HDR 4K LED Video Wall is its user-friendly installation process. The components are designed for easy assembly, allowing technicians to set up the video wall efficiently. This not only saves time but also ensures that the display is up and running quickly, minimizing disruptions in your space.
The BIA HDR 4K LED Video Wall takes visual clarity to a whole new level with High Dynamic Range (HDR) and 4K resolution. HDR enhances contrast and color, providing a more lifelike and vibrant display. Coupled with 4K resolution, the video wall delivers an incredibly detailed and sharp image that will leave viewers in awe, whether they are watching videos, presentations, or live events.
The BIA HDR 4K LED Video Wall has gained immense popularity in various industries due to its exceptional performance and stunning visuals. From command centers and control rooms to retail spaces and entertainment venues, this video wall has become a go-to solution for those seeking a top-tier display experience.
The versatility of the BIA HDR 4K LED Video Wall extends across a spectrum of applications. In a corporate setting, it serves as an impactful tool for presentations and data visualization. In retail, it attracts customers with dynamic advertising. In command centers, it provides a comprehensive view of critical information. The benefits are clear: enhanced communication, engagement, and an overall impressive visual experience.
In conclusion, the BIA HDR 4K LED Video Wall is a technological masterpiece that elevates visual displays to new heights. With its advanced components, sleek design, easy installation, HDR 4K visuals, and widespread popularity, it’s no wonder that businesses and industries around the world are embracing this cutting-edge solution. Experience the future of visual technology with BIA HDR 4K LED Video Wall.
Product Technical Specifications | ||||
| Product Name | AT09 | AT12 | AT15 | AT18 |
| Pixel Configuration | SMD | SMD | SMD | SMD |
| Pitch (mm) | 0.945 | 1.26 | 1,575 | 1.89 |
| Module Resolution (WxH) | 320×180 | 240×135 | 192×108 | 160×90 |
| Module Size (mm) (WxH) | 302.4×170.1 | 302.4×170.1 | 302.4×170.1 | 302.4×170.1 |
| Module Weight (Kg) | 0.65 | 0.65 | 0.65 | 0.65 |
| Module Composition (WxH) | 1×4 | 1×4 | 1×4 | 1×4 |
| Panel Resolution | 240×540 | 192×432 | 160×360 | 320×720 |
| Panel Dimension (WxHxD, mm) | 302.4 x 680.4 x 29.5 | 302.4 x 680.4 x 29.5 | 302.4 x 680.4 x 29.5 | 302.4 x 680.4 x 29.5 |
| Unit Area (m²) | 0.2058 | 0.2058 | 0.2058 | 0.2058 |
| Panel Weight (kg/m²) | 27 | 27 | 27 | 27 |
| Pixel Density (pixel/m²) | 1119789 | 629882 | 403124 | 279947 |
| Surface Flatness (mm) | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 |
| Brightness Calibration | Yes | Yes | Yes | Yes |
| Colour Calibration | Yes | Yes | Yes | Yes |
| Brightness (nits) (after calibration) | 600 | 600 | 600 | 600 |
| Colour Temperature | 3000-10000 K (adjustable) | 3000-10000 K (adjustable) | 3000-10000 K (adjustable) | 3000-10000 K (adjustable) |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Vertical Viewing Angle | 140° | 140° | 140″ | 140° |
| Deviation of LED Luminance Centre | <3% | <3% | <3% | <3% |
| Brightness Uniformity | ≤97% | ≤97% | ≤97% | ≤97% |
| Chromaticity Uniformity (after correction) | ±0.003Cx, Cy within | +0.003Cx, Cy within | ±0.003Cx, Cy within | +0.003Cx, Cy within |
| Contrast Ratio | 7000:1 | 7000:1 | 7000:1 | 7000:1 |
| Max. Power Consumption per Cabinet | 150 W | 130 W | 130 W | 130 W |
| Avg. Power Consumption per Cabinet | 50 W | 43 W | 43 W | 43 W |
| Max. Power Consumption per m² | 729 W | 632 W | 632 W | 632 W |
| Avg. Power Consumption per m² | 243 W | 209 W | 209 W | 209 W |
| Power Supply | Planar Remote Power Supply (RPS) | |||
| Frame Rate | 50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz |
| Refresh Rate | 3000/3840 Hz | 3000/3840 Hz | 3000/3840 Hz | 3000/3840 Hz |
| Lifetime | 100,000 hrs | 100,000 hrs | 100,000 hrs | 100,000 hrs |
| Operation Temperature | -10-40 °C | |||
| Storage Temperature | -20-60 °C | |||
| Operation Humidity (RH) | 10-80% no condensation | |||
| Storage Humidity (RH) | 10-85% по condensation | |||
| Certificates | CE/FCC/CB/cTUVus/CCC | |||
