Drive down any major artery in Pakistan—be it the Canal Road in Lahore, Sharah-e-Faisal in Karachi, or the Expressway in Islamabad—and you are bombarded by light. The era of static vinyl billboards is fading, replaced by the vibrant, moving imagery of SMD (Surface-Mounted Device) screens. For advertisers and building owners, the shift is lucrative, but the initial capital expenditure is significant.
The most frequent inquiry we handle is: What is the exact Outdoor SMD screen price in Pakistan?
Unlike buying a television where the price is fixed, an outdoor LED project is a construction project. The price fluctuates based on weatherproofing requirements (IP ratings), brightness levels (Nits), and structural steel costs. In this comprehensive analysis, we will breakdown the Outdoor SMD screen price in Pakistan for 2025, ensuring you have a realistic budget before you break ground.
The 2025 Pricing Landscape in Pakistan
To give you an immediate benchmark, here is the estimated market range for the screen body (panels only) as of 2025. Note that these rates are heavily influenced by the Dollar-to-PKR exchange rate.
| Pixel Pitch | Resolution Quality | Application | Estimated Price (PKR/Sq. Ft) |
|---|---|---|---|
| P3 Outdoor | Ultra High (4K Ready) | Walkways, Eye-Level Signage | PKR 38,000 – 48,000 |
| P4 Outdoor | High Definition | Low Height Fascias, Plazas | PKR 32,000 – 42,000 |
| P5 Outdoor | High Definition | Commercial Building Fronts | PKR 28,000 – 35,000 |
| P6 Outdoor | Standard HD | Mid-Range Billboards | PKR 24,000 – 32,000 |
| P8 Outdoor | Standard | Large Hoardings (>20ft height) | PKR 20,000 – 26,000 |
| P10 Outdoor | Entry Level | Massive Highway Poles | PKR 15,000 – 22,000 |
Disclaimer: These are estimated figures for the “Screen Body” excluding structure. For a precise quote, please Contact Us.
P10 vs. P6: Understanding the Price Gap
The Outdoor SMD screen price in Pakistan varies significantly between P10 and P6. Why?
P10: The Highway King
P10 (10mm between pixels) is the industry standard for massive pole signs (60ft x 20ft). Because the audience is viewing the screen from a moving car 50+ feet away, high resolution isn’t necessary. P10 modules use fewer LEDs per square foot (10,000 dots/m²), making them the most affordable option. If you see a giant screen on the Ring Road, it is likely a P10.
P6 and P8: The Commercial Standard
As you move into commercial areas like Tariq Road or Liberty Market, the viewing distance drops to 20-30 feet. Here, a P10 screen would look “blocky” or pixelated. Advertisers demand sharper text. P6 (27,777 dots/m²) packs nearly three times the pixel density of P10, leading to a higher Outdoor SMD screen price in Pakistan. However, the visual impact allows for premium advertising rates.
P3 and P4: The Future of Street Signage
For screens installed at eye level—such as outside a clothing brand’s outlet or a restaurant drive-thru—you need P3 or P4. These are expensive, often costing double the price of P10, but they deliver TV-like quality that withstands direct sunlight.
Critical Cost Factors for Outdoor Screens
When you receive a quotation that is surprisingly low, check the specifications. The Outdoor SMD screen price in Pakistan is driven by three technical pillars: Brightness, Weatherproofing, and Component Quality.
1. Brightness (Nits)
Indoor screens need only 800 nits. Outdoor screens must compete with the Pakistani sun, requiring 5,500 to 7,500 nits.
- Standard Brightness (5000 nits): Cheaper, but looks washed out at noon.
- High Brightness (7000+ nits): Increases the Outdoor SMD screen price in Pakistan by 10-15%, but ensures your ad is visible even in direct June sunlight.
2. Weatherproofing (IP Rating)
Pakistan’s climate is harsh. We face monsoon rains, dust storms, and extreme heat.
- IP65 (Front)/IP54 (Rear): The standard. Good for rain but requires a sealed cabinet.
- IP68 (Fully Waterproof): Premium modules that can practically be submerged. Using an indoor module or a poorly sealed outdoor module will result in water damage within the first rainy season, rendering your investment worthless.
3. Cabinet Material: Iron vs. Aluminum
- Iron Cabinets: Heavy and prone to rust after 2-3 years, but very cheap.
- Die-Cast Aluminum: Lightweight (saving on structural costs) and rust-proof. It dissipates heat better, extending LED life. While it raises the initial Outdoor SMD screen price in Pakistan, it lowers maintenance costs.
The Hidden Costs: Structure and Installation
A common mistake buyers make is budgeting only for the screen panels. In reality, the Outdoor SMD screen price in Pakistan is just 60-70% of the total project cost. You must account for the “Civil Work.”
Structural Engineering
A 20ft x 10ft screen weighs heavily and acts like a sail in the wind. You cannot simply bolt it to a wall.
- Roof Top: Requires steel beams anchored into the building’s columns.
- Pole/Unipole: Requires deep excavation (piling) and heavy-gauge steel pipes.
- Cost: Structural steel works typically cost between PKR 800 to PKR 1,500 per square foot, depending on steel prices and height.
Cladding and Aesthetics
You don’t want exposed wires and iron bars visible from the side. Alucobond (Aluminum Composite Panel) cladding is used to frame the screen, adding a finished look. This aesthetic finish is charged per square foot of the frame area.
Power Infrastructure
Outdoor screens are power-hungry. A large screen might pull 20-30 Kilowatts.
- 3-Phase Meter: You may need a dedicated commercial meter.
- Cabling: Heavy-duty 4-core armored cables are expensive.
- Distribution Box (DB): A custom DB with digital volt meters, amp meters, and surge protection is mandatory to protect the screen from WAPDA fluctuations.
Regional Considerations: Karachi vs. Lahore vs. Islamabad
The Outdoor SMD screen price in Pakistan can also vary by location due to environmental protections.
- Karachi (Coastal Humidity): The salt in the air corrodes iron cabinets rapidly. For Karachi, we strictly recommend Die-Cast Aluminum cabinets or heavily galvanized iron with conformal coating on the PCBs. This adds to the cost but is non-negotiable for longevity.
- Lahore/Multan (Extreme Heat): Temperatures exceed 45°C. The screen generates its own heat. If the internal temperature passes 60°C, the power supplies will fail. In these cities, we must install industrial exhaust fans or even Air Conditioners inside the maintenance corridor behind the screen.
Why Quality Matters: The “Gold Wire” Difference
At SMD LED, we often get asked why our quote might be slightly higher than a generic roadside vendor. The secret lies inside the LED lamp.
- Copper Wire LEDs: Standard, cheaper, but prone to oxidation and failure.
- Gold Wire LEDs: Used in our premium BIA Outdoor SMD Screen Modules. Gold is non-corrosive and conducts electricity better, ensuring the screen stays bright for 5-7 years.
Opting for the cheapest Outdoor SMD screen price in Pakistan usually means getting Copper wire LEDs, which may start showing “dead pixels” or color shifts (white turning pink) within 12 months.
Calculating ROI: Is it Worth It?
Despite the high Outdoor SMD screen price in Pakistan, the ROI is compelling.
- Static Billboard: Can only display one client per month.
- Digital Billboard: Can display 10+ clients in a loop (10-second slots). If you charge PKR 100,000 per slot, a digital board can generate PKR 1 Million+ per month, paying for itself in under a year.
Conclusion
The Outdoor SMD screen price in Pakistan is an investment in visibility and durability. For 2025, budget between PKR 15,000 to PKR 35,000 per square foot for the screen, plus an additional 20-30% for structure and installation.
Don’t let the initial numbers scare you. The durability of a well-built outdoor screen, specifically one using high-quality BIA Outdoor SMD Screen Modules, ensures consistent revenue generation or brand awareness for years.
We strongly recommend visiting our Products Page to view the specifications of our outdoor cabinets. For a turnkey solution that includes structure, installation, and after-sales support, Contact Us today.
Frequently Asked Questions (FAQs)
1. What is the total Outdoor SMD screen price in Pakistan for a 10×20 ft billboard? For a standard P10 outdoor screen (200 sq. ft.), the screen body might cost around PKR 3.2 Million to 4 Million. However, adding the steel structure, cladding, installation, and power setup, the total project cost often lands between PKR 4.5 Million to PKR 5.5 Million.
2. Does the outdoor SMD screen price include electricity costs? No, the Outdoor SMD screen price in Pakistan refers to the hardware. Operational costs are separate. An average outdoor screen consumes about 300-600 Watts per square meter depending on brightness. You should budget for monthly commercial electricity bills.
3. Why is the P6 outdoor screen price higher than P10? P6 screens have a higher pixel density (more LEDs per square meter). This requires more LED lamps, more driver ICs, and more complex PCB manufacturing. Therefore, the Outdoor SMD screen price in Pakistan for P6 is typically 30-40% higher than P10, but it offers much sharper image quality for closer viewing distances.
4. Can I use an indoor screen outdoors to save on the price? Never. Indoor screens are not waterproof and lack the brightness to be seen in daylight. Using an indoor screen outside will result in immediate water damage and zero visibility during the day. The lower price is not worth the total loss of investment.
5. How long does an outdoor SMD screen last in Pakistan’s weather? A high-quality outdoor screen with proper cooling and IP65 protection can last 7-10 years (approx. 100,000 hours). However, regular maintenance (cleaning dust, checking fans) is crucial. Cheaper screens with low Outdoor SMD screen price in Pakistan often fail within 1-2 years due to heat damage or corrosion.
