Getting Approval for an Outdoor SMD Screen in Lahore: A Practical Guide

Important: this is a general guide, not legal advice. Outdoor advertising in Lahore is controlled by different bodies depending on where the screen stands (for example the Parks & Horticulture Authority, the Lahore Development Authority, DHA or the Cantonment Board), and their requirements change. Always confirm the current process with the authority that controls your site before you buy or install a screen.

An outdoor SMD screen in Lahore is a large electrical structure in a public place, so it needs permission before it goes up. Planning the approval early saves you from delays, changes to the design or an order to remove the screen later.

Step 1: Find out who controls your site

The first question is not the screen but the land. A rooftop on a main road, a shop front inside a housing society and a plot in a cantonment area can each fall under a different authority. Ask your landlord or society office which body approves outdoor advertising for that exact address, and get the name of the office that handles it.

Step 2: Get the owner’s written consent

If you do not own the building or plot, you need written permission from the owner or the society. Authorities usually ask for it, and it protects you if the property changes hands.

Step 3: Prepare the technical documents

Authorities typically want to see that the screen is safe and will not disturb traffic or neighbours. Be ready with:

• Site plan and photos showing exactly where the screen will be and how it faces the road.
• Screen drawings with size, height above ground and the supporting structure.
• Structural safety: a structural engineer’s confirmation that the frame and wall or roof can carry the screen and wind load.
• Electrical safety: proper earthing, protection and cabling done by a qualified electrician.
• Brightness control: an automatic light sensor so the screen dims at night and does not dazzle drivers.

We can help you prepare the screen drawings, specifications and brightness details so that your engineer and the authority have what they need.

Step 4: Submit, then wait for written approval

Submit the application to the office that controls your site and keep copies of everything. Do not install the screen until you have the approval in writing; changing a structure after it is built is far more expensive than changing a drawing.

Step 5: Install and run the screen responsibly

• Install exactly what was approved: same size, position and height.
• Keep the brightness sensor working and follow any operating hours the authority sets.
• Avoid fast flashing content near junctions and traffic signals.
• Keep the approval documents and renew them when required.

Fix the screen specification before you apply

An application describes a specific screen, so it helps to settle the main details first. Changing the size or position after submission can mean starting again.

• Size and position: width, height, height above ground, and which direction the screen faces.
• Pixel pitch: as a rule of thumb, the minimum comfortable viewing distance in metres is roughly equal to the pitch in millimetres. A roadside screen seen from a distance can use a coarser pitch than a screen at a shop entrance. Our pixel pitch guide explains how to choose.
• Brightness: outdoor screens usually need around 4,500 to 6,500 nits to be readable in direct sun, and should dim automatically after dark.
• Protection: the cabinets should have at least an IP65 front rating for dust and monsoon rain, and an operating temperature range suited to Lahore’s summer heat.

Structure: rooftop, wall or pole

The mounting type affects both the engineering and the paperwork. Each option needs its own checks by a qualified structural engineer:

Steel frames outdoors should be protected against corrosion, and drainage should be planned so rainwater does not collect behind the screen. Include a safe way for technicians to reach the screen for service, especially for rear-service cabinets.

Electrical details authorities and engineers look for

• A dedicated supply sized for the screen’s maximum power figure from the datasheet.
• A distribution board with suitable breakers and surge protection.
• A proper earthing system for the frame and cabinets.
• Weather-protected cabling and connectors.
• A plan for load-shedding and generator or UPS changeover so the screen restarts safely.

The controller, for example a NovaStar sending card or media player with a light sensor, should be set up so brightness and operating hours can follow any conditions in your approval.

Common reasons applications get delayed

• The application is sent to the wrong authority for the site.
• Owner or society consent is missing or unclear.
• Drawings do not show the height, size and road-facing direction clearly.
• No structural confirmation from a qualified engineer.
• No information on night-time brightness control.

Document checklist

• Name of the authority and office for your exact site
• Owner or society written consent
• Site plan, photos and screen position
• Screen drawings and datasheet
• Structural engineer’s confirmation
• Electrical and earthing details
• Brightness control and operating hours
• Copies of everything submitted

Our services cover screen selection, technical documents and installation once approval is in hand.

Frequently asked questions

Do indoor screens need the same approval?

Screens fully inside a shop or hall are usually treated differently from outdoor advertising, but building and fire-safety rules still apply. Check with your building management.

Can SMDLED handle the approval for me?

We supply the technical drawings, specifications and brightness details that applications need, and we can coordinate with your engineer. The application itself is made by the site owner or advertiser to the relevant authority.
