BIA Plus SMD Screen Module

Overview

The BIA Plus SMD Screen Module is an indoor LED module in a 16:9 format (320 × 180 mm), offered in pixel pitches from 1.25 mm to 2.5 mm. Because each module has the same shape as standard video, 16:9 content fits a wall built from whole modules without cropping or black bars.

For example, a wall ten modules wide and ten high in the 1.667 mm pitch (192 × 108 pixels per module) gives exactly 1920 × 1080 pixels, a Full HD wall 3.2 m wide and 1.8 m high.

Choosing a Pitch

The finer pitches (1.25 to 1.86 mm) suit boardrooms, control rooms and reception walls where people stand close to the screen. The 2 and 2.5 mm pitches suit larger rooms and halls viewed from further back. The specification table below lists brightness, power and refresh rate for each model; our pixel pitch guide explains how to match pitch to viewing distance.

Applications

• Boardrooms and meeting rooms
• Control rooms and data dashboards
• Reception and lobby walls
• Showroom and retail feature walls
• Studios and event stages

Warranty and Support

Every installation carries a one year warranty. Ask us for the module warranty terms for your project when we prepare your quote. Our team surveys the site, installs and calibrates the wall, and remains available for service after handover.
